About DE-RAY
A Leader in VCSEL Laser field.
DE-RAY Optoelectrics is a 4-inch New Gen VCSEL laser production platform based on the IDM (Integrated Device Manufacturer) full industry chain model, integrating research and development, design, epitaxial, chip manufacturing, testing, and failure analysis.
.png)
Uchikanda, Chiyoda-ku, Tokyo
No. 76 Luozhu Road
Nanchang City, Jiangxi Province, CHINA
$ 50397K
358797
Sq.ft
452084
32291
Sq.ft
Paid-in Registered Capital
Angel round and Pre A investment have been completed.
The Round A is expected to be completed within 12 months.
Support continuous R&D investment and product innovation，provide more reliable products with competitive prices in the international market.
We are honored to grow together with our customers.
Own Independent Park
IDM (Integrated Device Manufacturer) model, with its own wafer fab, packaging plant and testing plant, to complete the entire life cycle of the chip.Full process control from design to manufacturing, quality assurance.
Coordinated optimization from design to manufacturing, rapid response to customers.Full utilization of technical potential, bringing leading products to customers.
Workshop and Clean Room
24 hours, 365 days, Non-Stop high-standard clean room, the highest standard 100 clean room. Tape Out, Extension and other key equipment are all from first-class equipment manufacturers.Provide customers with VCSEL lasers with wavelengths from 650nm to 1600nm and various powers, respond quickly to customer needs, and accept customer customization to meet the increasingly changing market environment.
Explore VCSEL and Services
A Leader In VCSEL Laser Field. Accept customization, low MOQ, New Gen VCSEL SMD helps you reduce processing costs. menu-based selection, help quickly complete product development.
VCSEL
New Gen VCSEL (Vertical - Cavity Surface - Emitting Laser) can complete the process manufacturing and testing directly on the Wafer, which is suitable for large - scale commercial use and has obvious cost advantages.
The wavelength of New Gen VCSEL is less affected by the environmental temperature. Especially compared with other lasers, it has higher stability.
Compared with edge - emitting lasers, New Gen VCSEL can be integrated into a 2D array to meet the requirements of different optical powers and transmission distances, and it can be theoretically integrated infinitely.
New Gen VCSEL is widely used in fields such as data communication, optical sensing, facial recognition, lidar, and medical cosmetology.
VCSEL has development trends in high transmission rate, high emission power, multi - junction addressable technology, etc., and its broad prospects can be expected.
VCSEL SMD
VCSEL Die
Tailored Design
Services
With the booming development of AI and health industries, the semiconductor laser industry has ushered in new growth opportunities. From medical diagnosis, personal care and beauty to intelligent manufacturing, VCSEL semiconductor lasers play a key role in many fields.Semiconductor industry segmentation is crucial. Different segments focus on specific needs, improve technical accuracy and efficiency, and shorten product development.
The integration and synergy of the industrial chain can achieve optimal resource allocation and enhance overall competitiveness.International cooperation can bring advanced technology and experience, while independent development ensures that core technology is in our own hands. The two complement each other and jointly promote the semiconductor laser industry to a new height and contribute to global scientific and technological progress.
Tailored Module
Circuit Design
Service For Fabless
Ready to innovate your products
with New Gen VCSEL Laser?
